Bag in Box Filler BBF14Bag in Box Filler BBF14


The bag-in-box filler BBF14 is a semiautomatic filling machine which can be used to fill single bags and bag on tape. By the amount measurement, it is possible to fill   3 l-, 5 l-, 10 l- and 20 l-bags. The bags are put in easily and very quickly. This machine suits for cold filling as well as for hot filling up to 80 °C.



Operation: one bag bag on tape
insert bag manuel automatic
open the bag fastener     automatic     automatic
generate vacuum automatic automatic
bag filling automatic automatic
close the bag automatic automatic





Connection: 3/N/P 400 V
Connection plug: CEE 5-pin 16 A
Compressed air: 6 bar
Filling performance /h (bag on tape): approx. 330 pcs./3l   approx. 280 pcs./5l   approx. 250 pcs./10l
Length: 1100 mm
Width: 900 mm
Height: 1600 mm
Weight: 210 kg



item number designation
100-0007-0140 BBF14




Titelbild Bedienung BBF14 BM Titelbild Bedienung BBF14 EM
Operation in from belt mode Operation in single mode





Operating instructions





Bag supply
Bag feeder BZF14



Illustrations and technical data are not binding. Design changes are reserved.
