Steam Generators
This Turbo Steamer finds its optimal application in small to medium sized wineries
Sterilization of depth filters, candle filters, and filling machines
To steam tanks before storage
Remove tartar
Water is supplied to the turbo steamer via the water connection at a minimum pressure of 3 bar. This water is heated in approximately one minute until steam is generated. The resulting steam flows out of the steam outlet.
Steam Generator TD9
Specifications:
Electrical power rating: 9,9 kW
Electrical connection: 3 phase / N / PE 400 V AC 50 Hz
Electrical connector: male CEE 5 pol. 16 A
Mains cable: approx. 5 m
Fusing: 16 A
Water connection: GeKa coupling
Steam output connection: NW 25
Minimum water pressure: 3 bar
Maximum steam pressure: 2,5 bar
Amounts of steam: 15 kg per hour
Weight: approx. 50 kg
Length x width x height: 760 mm x 345 mm x 690 mm
Steam Generator TD13
Specifications:
Electrical power rating: 13,2 kW
Electrical connection: 3 phase / N / PE 400 V AC 50 Hz
Electrical connector: male CEE 5 pol. 32 A
Mains cable: approx. 5 m
Fusing: 20 A
Water connection: GeKa coupling
Steam output connection: NW 25
Minimum water pressure: 3 bar
Maximum steam pressure: 2,5 bar
Amounts of steam: 20 kg per hour
Weight: approx. 55 kg
Length x width x height: 760 mm x 345 mm x 690 mm
Steam Generator TD16
Specifications:
Electrical power rating: 16,5 kW
Electrical connection: 3 phase / N / PE 400 V AC 50 Hz
Electrical connector: male CEE 5 pol. 32 A
Mains cable: approx. 5 m
Fusing: 25 A
Water connection: GeKa coupling
Steam output connection: NW 25
Minimum water pressure: 3 bar
Maximum steam pressure: 2,5 bar
Amounts of steam: 25 kg per hour
Weight: approx. 60 kg
Length x width x height: 760 mm x 345 mm x 690 mm
Steam Generator TD23
Specifications:
Electrical power rating: 23,1 kW
Electrical connection: 3 phase / N / PE 400 V AC 50 Hz
Electrical connector: male CEE 5 pol. 63 A
Mains cable: approx. 5 m
Fusing: 35 A
Water connection: GeKa coupling
Steam output connection: NW 25
Minimum water pressure: 3 bar
Maximum steam pressure: 2,5 bar
Amounts of steam: 35 kg per hour
Weight: approx. 80 kg
Length x width x height: 910 mm x 510 mm x 760 mm
Steam Generator TD33
Specifications:
Electrical power rating: 33 kW
Electrical connection: 3 phase / N / PE 400 V AC 50 Hz
Electrical connector: male CEE 5 pol. 63 A
Mains cable: approx. 5 m
Fusing: 50 A
Water connection: GeKa coupling
Steam output connection: NW 25
Minimum water pressure: 3 bar
Maximum steam pressure: 2,5 bar
Amounts of steam: 50 kg per hour
Weight: approx. 100 kg
Length x width x height: 910 mm x 510 mm x 760 mm
Accessories
We also offer a wide range of accessories for our steam generators. Contact us!
Barrique Barrel Steam Adapter BFD20
How to steam a barrique barrel
Steam Junction Box
Steam Hose
Service
Videos and guides on commissioning, operation and maintenance
Operating instructions TD multilingual
How to set-up the steam generator
How to clean and descale a steam generator
Abbildungen und technische Daten sind unverbindlich
Konstruktionsänderungen bleiben vorbehalten
